Sun protection systems

Sun protection solutions for windows, doors, roofings and curtain walls

heroal textile sun protection systems stand out for their great flexibility and unique variety of designs. The end-strip guided heroal VS, the heroal VS C with stainless steel rope guidance, and the zip-guided heroal VS Z make it easy to meet individual customer needs and different technical requirements. The cross-system design principle, the utilisation of standard parts and well-thought-out design details provide for an extremely efficient and easy fabrication.

Go to product

Your advantages

Download brochure

You can find all the information relating to our sun protection systems in our brochure.

Brochure heroal sun protection systems

Brochure heroal VS Z kit

Zip Screen System

System products can be ordered for the entire heroal product portfolio. The profiles are supplied in lengths and all processing is carried out by the fabricator.

System comparison:

heroal VS Z
heroal VS C
heroal VS
heroal VS Z corner solution
heroal VS Z CS partly integrated
  • System dimensions

    Box size [mm]
    heroal VS Z 85**, 95, 105, 125 heroal VS C 85, 95, 105, 125 heroal VS 85**, 95, 105, 125 heroal VS Z Ecklösung 105, 125 heroal VS Z CS teilintegriert 85, 95, 105, 125
    Max. width [mm]
    heroal VS Z 6.000 heroal VS C 5.000 heroal VS 5.000 heroal VS Z Ecklösung 3.000 heroal VS Z CS teilintegriert 6.000
    Max. height [mm]
    heroal VS Z 5.000 heroal VS C 5.000 heroal VS 5.000 heroal VS Z Ecklösung 3.000 heroal VS Z CS teilintegriert 5.000
    Max. area [m2]
    heroal VS Z 18 heroal VS C 15 heroal VS 15 heroal VS Z Ecklösung 9 heroal VS Z CS teilintegriert 18
    Minimum lintel required [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---
    Coverage width [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---
    Nominal thickness [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---

Zip Screen System for canopies

heroal VS Z systems as a kit

The heroal kit includes precisely cut and machined panels, guide rails, end strips and matching cover caps in the selected system color. Supplemented by the textile assembly, the kit also contains the made-to-measure textile assembly and the corresponding guide rail insert, also cut to size.

System comparison:

heroal VS Z
heroal VS C
heroal VS
heroal VS Z corner solution
heroal VS Z CS partly integrated
  • System dimensions

    Box size [mm]
    heroal VS Z 85**, 95, 105, 125 heroal VS C 85, 95, 105, 125 heroal VS 85**, 95, 105, 125 heroal VS Z Ecklösung 105, 125 heroal VS Z CS teilintegriert 85, 95, 105, 125
    Max. width [mm]
    heroal VS Z 6.000 heroal VS C 5.000 heroal VS 5.000 heroal VS Z Ecklösung 3.000 heroal VS Z CS teilintegriert 6.000
    Max. height [mm]
    heroal VS Z 5.000 heroal VS C 5.000 heroal VS 5.000 heroal VS Z Ecklösung 3.000 heroal VS Z CS teilintegriert 5.000
    Max. area [m2]
    heroal VS Z 18 heroal VS C 15 heroal VS 15 heroal VS Z Ecklösung 9 heroal VS Z CS teilintegriert 18
    Minimum lintel required [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---
    Coverage width [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---
    Nominal thickness [mm]
    heroal VS Z --- heroal VS C --- heroal VS --- heroal VS Z Ecklösung --- heroal VS Z CS teilintegriert ---

Sun protection finished elements heroal Ready

The heroal Ready prefabricated elements for roller shutters, sun shading and roller doors offer the highest degree of prefabrication. Specialist partners receive the products completely pre-assembled, allowing them to focus on sales and installation at the end customer. Partners benefit from maximum flexibility and efficiency, especially in times of high order volumes.
